Tandem Axle Utility Trailers


These 6’ 9” wide trailers are available in 14, 16, 18, and 20 foot lengths. With a larger tow capacity of 7000-10,000 GVW, these are very popular with landscapers and business owners who need to tow small tractors and heavy equipment.

  • DEXTER Sprung Axles
  • E-Z Lube Hubs with Grease Caps
  • USA MADE Grommet Mounted LED Recessed Lights W/Lifetime Warranty
  • All Wiring Harness Run in Conduit
  • “2×8” Pressure Treated Decking
  • Jack 7000LB Drop Leg
  • 6way RV Front Plug
  • 4 Colors to Choose from, Red, Blue, Black, Green. Other colors available
  • Curb Weight: 1535 lbs. (U7000B12)
  • Bed Width: 6’-9″ (81”)
  • Bed Height: 19”
  • Overall Width: 8’-5” (101″)
  • Axles (Dual): (2) 3,500 lbs. Brake axle for 7000 GVW, (2)6000Lb Brake for 10,000 GVW
  • Tires: ST205/75R15 LR-C
  • Wheels: White Spoke 15”-5 lug (5 on 4.5)
Model Specifications
Model NumberSizeGVW
U7000B126’9”x12’7000 LBS
U7000B146’9”x14’7000 LBS
U7000B166’9”x16’7000 LBS
U7000B186’9”x18′7000 LBS
U10000B186’9”x18’10000 LBS
U10000B206’9”x20’10000 LBS
Options
  • 12” Mesh Sides
  • 24” High Sides
  • 5’ Standard Split Gate
  • Spare Tire
  • Heavy Duty Gate
  • HD 5’ Gate
  • Extra Tie Downs
  • XHD Gate W/Drop Leg
